- Place of Origin: SHENZHEN
- Brand Name: DETECTOR ZK
- Model Number: ZK-803A
- Weight: 65.000 kg
Performance and Features
u Operation: Touch screen.OSD are English and Chinese.It is easy to operate.
u Temperature measurement function: It can accurately scan the temperature of forehead or wrist. It will have the voice alarm when the temperature is higher than body’s normal temperature.
u Anti-interference ability: Digital, analog and balanced technology to prevent the false alarm and omission,greatly hanced anti-jamming ability.
u Security protection: Using Only allow authorized person to operate it.
u Intelligent statistics :It can count the quantities of passer and alarms.
u Harmless:It is harmless to the heart pacemaker, pregnant, disk,film ect .
u Installation:It will take 20minutes to install or remove the device.
Temperature diagnose
Just like a temperature gauge,can automatically diagnose the human temperature when walk through,it efficaciously prevent the sickness spread.Specially can be used at custom where people come and go frequently.
- Place of Origin: SHENZHEN
- Brand Name: DETECTOR ZK
- Model Number: ZK-803A
- Weight: 65.000 kg
Technical Parameters
Detect Metal | 1. LED Indicators: | The both sides LED Indicators will show the metal location exactly |
2. Detection zones: | Divided into 6 overlapping zones basic on human body to avoid the weak/blind areas. | |
2. Detection zones: | Sound &Visual Alarm. It will show the location of the forbidden metal hidden in human body such as weapon and knives exactly with the Corresponding height LED indicators in both side door panel. | |
4. Sensitivity: | 1000 sensitivity steps in each program. Separate vertical zones with independently adjustable sensitivity from 0-999. | |
5. Password protection: | Only allow the authorizes to operate. The password can be revised as requirement. It is high safe | |
6. Intelligent statistics: | Can count the pass and alarms automatically. | |
7. Easy to installation: | Just take 10mins to install or remove follows user’s manual. | |
8. Harmless to human body: | Reaching the EMC electromagnetic radiation, harmless to the heart pacemaker, pregnant, the floppy disk, film and video etc. | |
Scan Temperature | 9. Temperature diagnose | Just like a temperature gauge,can automatically diagnose the human temperature when walk through,it efficaciously prevent the sickness spread.Specially can be used at custom where people come and go frequently. |
10.Display | 7" LCD Touch Screen | |
11. Sensor | 2 infrared sensors | |
12.Accuracy | 1% or ±0.3℃ | |
13.Response time | Less than 0.5s | |
14.Detection distance | 2-5cm | |
Specification: | Operating temperature: | from -30 ℃ to 55 ℃ |
Humidity: | 0 to 98% | |
Power supply: | AC90V-250V, 50HZ-60HZ | |
Power consumption | ≤30W | |
Warranty: | 1year | |
Dimension: | The size of the passage: 2000mm(h)*700mm(w)*560mm(d) | |
Dimensions of the control cabin : 2200mm(h)*800mm(w)*560mm(d) | ||
Color: | Silver white | |
Packing detail: | Door Panel: 232x72x22cm | |
Overhead control unit: 80x52x30cm | ||
